RTD-3D3Q
| Availability: | |
|---|---|
| Quantity: | |
Multi-Purpose Design: Switch between garden spraying (fertilizer, pesticides) and power washing (patio, vehicles) with no tool changes .
User-Friendly Operation: Ergonomic spray gun with trigger lock reduces operator fatigue during extended use .
Durable Residential Construction: Weather-resistant casing and stainless steel components withstand outdoor storage and seasonal use .



The RTD-3D3Q Garden Sprayer Pump Set is a versatile domestic and light-commercial system combining a triplex plunger pump with a portable sprayer assembly. This integrated set features a corrosion-resistant aluminum pump body and brass spray nozzles , delivering a maximum pressure of 2,900 psi (200 bar) and a flow rate of 4.2 gpm (16 L/min) . The sprayer includes a 20-liter detergent tank and 5 interchangeable nozzles (0°, 15°, 25°, 40°, soap) for targeted cleaning. Weighing 38 kg with a 10-meter high-pressure hose, it balances portability and performance for home use .
Residential Cleaning: Cleans patios, decks, driveways, and vehicles; removes mold and mildew from exterior surfaces.
Garden Maintenance: Applies insecticides, herbicides, and liquid fertilizers to lawns, shrubs, and flower beds .
Light Commercial Use: Cleans small storefronts, outdoor furniture, and rental property exteriors for landscaping businesses .
Q: What power source does the RTD-3D3Q Set use?
A: It operates on single-phase 220V/50Hz or 110V/60Hz power, with a rated motor power of 2.2 kW (3 hp) .
Q: How far does the spray reach with the garden nozzle?
A: The fan nozzle achieves a horizontal spray distance of 12 meters for wide-area garden coverage .
Q: Is assembly required before use?
A: Minimal assembly is needed—attach the hose and nozzle in 10 minutes , no specialized tools required .
